Freeradius 3.2.8 on Debian 12 not responding to requests via Relay Agent
David Lake
d.lake at surrey.ac.uk
Thu Jul 17 14:56:56 UTC 2025
Hello
I’m trying to configure FreeRadius to offer addresses to a remote subnet behind a DHCP Relay agent.
My local IP range is 192.168.1.0/24 with the server at 192.168.1.1
My remote range is 192.168.2.0/24 with the Relay Agent at 192.168.2.1.
I have two pools in dhcpippool using MySQL
MariaDB [radius]> select * from dhcpippool;
+----+-----------+-----------------+------------------+-------------+---------------------+---------+---------+
| id | pool_name | framedipaddress | pool_key | gateway | expiry_time | status | counter |
+----+-----------+-----------------+------------------+-------------+---------------------+---------+---------+
| 9 | local | 192.99.0.102 | 0x01d076580cbb80 | 0.0.0.0 | 2025-07-16 23:47:58 | dynamic | 0 |
| 10 | local | 192.99.0.101 | | 192.99.0.1 | 2025-07-16 17:58:09 | dynamic | 0 |
| 11 | local | 192.99.0.100 | | 192.99.0.1 | 2025-07-16 21:51:58 | dynamic | 0 |
| 12 | ipoe | 192.168.2.100 | | 192.168.2.1 | 2025-07-17 14:00:33 | dynamic | 0 |
| 13 | ipoe | 192.168.2.101 | | 192.168.2.1 | 2025-07-17 14:00:39 | dynamic | 0 |
| 14 | ipoe | 192.168.2.102 | | 192.168.2.1 | 2025-07-17 14:00:44 | dynamic | 0 |
+----+-----------+-----------------+------------------+-------------+---------------------+---------+---------+
6 rows in set (0.003 sec)
MariaDB [radius]>
I can server hosts locally on 192.168.1.0 and everything works fine.
However, I’m seeing zero traffic incoming to radius -X even though tcpdump shows that traffic is being received on the eth0 interface (192.168.1.1). Pcap attached taken on the DHCP server machine.
Is there a config step I am missing? ss -lunp shows that radiusd is listening on port 67.
My files/dhcp is configured as follows:
#
network Pool-Name := "local"
DHCP-Domain-Name := "local.org",
DHCP-Subnet-Mask := 255.255.255.0,
DHCP-Router-Address := 192.168.1.1,
DHCP-Domain-Name-Server := 8.8.8.8,
Fall-Through := yes
network DHCP-Network-Subnet < 192.168.2.0/24, Pool-Name := "ipoe"
DHCP-Domain-Name := "remote.org",
DHCP-Subnet-Mask := 255.255.255.0,
DHCP-Router-Address := 192.168.2.1,
DHCP-Domain-Name-Server := 8.8.8.8,
Fall-Through := yes
DHCP in mods-enabled is:
listen {
# This is a dhcp socket.
type = dhcp
# IP address to listen on. Will usually be the IP of the
# interface, or 0.0.0.0
ipaddr = 192.168.1.1
# source IP address for unicast packets sent by the
# DHCP server.
#
# The source IP for unicast packets is chosen from the first
# one of the following items which returns a valid IP
# address:
#
# reply:Packet-Src-IP-Address
# If the request is unicast, the address it was received on
# src_ipaddr
# ipaddr
# reply:DHCP-DHCP-Server-Identifier
#
src_ipaddr = 192.168.1.1
# The port should be 67 for a production network. Don't set
# it to 67 on a production network unless you really know
# what you're doing. Even if nothing is configured below, the
# server may still NAK legitimate responses from clients.
port = 67
# Interface name we are listening on. See comments above.
interface = eth0
# The DHCP server defaults to allowing broadcast packets.
# Set this to "no" only when the server receives *all* packets
# from a relay agent. i.e. when *no* clients are on the same
# LAN as the DHCP server.
#
# It's set to "no" here for testing. It will usually want to
# be "yes" in production, unless you are only dealing with
# relayed packets.
broadcast = no
# On Linux if you're running the server as non-root, you
# will need to do:
#
# setcap cap_net_admin,cap_net_bind_service=eip /path/to/radiusd
#
# This will allow the server to set ARP table entries
# for newly allocated IPs, when run as the "radius" user.
#
# The above "setcap" command adds the capability to the program,
# usually so long as it is run by the "radius" user. Which means
# (oddly enough) that it no longer works when run as root!
#
# When running the server as root in debug mode, you can use:
#
# capsh --caps="cap_setpcap,cap_setuid,cap_setgid,cap_net_admin,cap_net_bind_service+eip" --keep=1 --user=radius --addamb=cap_net_admin,cap_net_bind_service -- -c "/path/to/radiusd -X"
#
# Or, simply "sudo" or "su" to the "radius" user, and then run
# the server in debug mode.
# De-duplicate DHCP packets. If clients don't receive
# a reply within their timeout, most will re-transmit.
# A reply to either packet will satisfy, so de-duplicating
# helps manage load on a busy server
performance {
skip_duplicate_checks = no
}
}
# Packets received on the socket will be processed through one
# of the following sections, named after the DHCP packet type.
# See dictionary.dhcp for the packet types.
# Return packets will be sent to, in preference order:
# DHCP-Gateway-IP-Address
# DHCP-Client-IP-Address
# DHCP-Your-IP-Address
# At least one of these attributes should be set at the end of each
# section for a response to be sent.
# An internal attribute of DHCP-Network-Subnet is set to provide
# a basis for determining the network that a client belongs to. This
# is a hierarchical assignment based on:
#
# - DHCP-Relay-Link-Selection
# - DHCP-Subnet-Selection-Option
# - DHCP-Gateway-IP-Address
# - DHCP-Client-IP-Address
#
# Except for cases where all IP allocation is performed using a mapping from
# the device MAC address to a fixed IP address the DHCP configuration will
# involve the use of one or more pools.
#
# Each pool should be composed of a set of equally valid IP addresses for the
# devices designated as users of the pool. During IP allocation the choice of
# pool is driven by setting the Pool-Name attribute which may either be
# specified directly or chosen (usually with the help of the dhcp_network
# module) based on the initial value of DHCP-Network-Subnet.
#
# DHCP-Network-Subnet indicates the network from which the request is
# originating. In cases where the originating network alone is insufficent to
# define the required IP allocated policy, DHCP-Network-Subnet may be
# overridden to force the selection of a particular pool.
#
# IP addresses belonging to a single pool that is designated for a Layer 2
# network containing multiple subnets (a "shared-network" or "multinet"
# configuration as defined by some other DHCP servers), will by definition be
# members of distinct subnets that require their own DHCP reply parameters. In
# this case the dhcp_subnet policy can be used to set the correct
# DHCP-Subnet-Mask, DHCP-Router-Address and DHCP-Broadcast-Address options
# based on the allocated IP.
dhcp DHCP-Discover {
# The DHCP Server Identifier is set here since is returned in OFFERs
update control {
&DHCP-DHCP-Server-Identifier = 192.168.1.1
}
# Call a policy (defined in policy.d/dhcp) to set common reply attributes
# dhcp_common
# Use a "passwd" module to set group memberships in DHCP-Group-Name
# Enable mods-available/dhcp_passwd to use this
#dhcp_group_membership
# If clients need to be assigned to a particular network based on
# an attribute in the packet rather than the calculated
# DHCP-Network-Subnet described above, then call a policy
# (defined in policy.d/dhcp) to perform the override
#dhcp_override_network
# Use a "files" module to lookup global and subnet options
# For multiple subnets use this in place of dhcp_common
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
dhcp_network
# Do a simple mapping of MAC to assigned IP.
#
# See below for the definition of the "mac2ip"
# module.
#
#mac2ip
# Or, allocate IPs from the DHCP pool in SQL. You may need to
# set the pool name here if you haven't set it elsewhere.
# update control {
# &Pool-Name := "local"
#}
dhcp_sqlippool
# If the IP address was not allocated, do something else.
# You could call a Perl, Python, or Java script here.
#if (notfound) {
# ...
#}
# "Shared-networks" may have multiple IP subnets co-existing in a
# single Layer 2 network. If the pool for the network contains
# addresses from more that one subnet then the setting subnet-specific
# DHCP-Subnet-Mask, DHCP-Router-Address and DHCP-Broadcast-Address
# parameters must be performed after the allocation of the IP address.
#
# Set any subnet-specific parameters using this policy.
#
# Enable mods-available/dhcp_files AND uncomment dhcp_subnet in
# policy.d/dhcp to use this.
#
#dhcp_subnet
# Use a "files" module to lookup options based on DHCP-Group-Name
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
#dhcp_group_options
# Use a "files" module to lookup host specific options
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
#dhcp_hosts
# As an alternative or complement to configuration files based lookup
# for options data you can instead use an SQL database. Example
# configuration is found in dhcp_policy_sql in policy.d/dhcp which
# will need to be adapted to your requirements.
#dhcp_policy_sql
# Set the type of packet to send in reply.
#
# The server will look at the DHCP-Message-Type attribute to
# determine which type of packet to send in reply. Common
# values would be DHCP-Offer, DHCP-Ack or DHCP-NAK. See
# dictionary.dhcp for all the possible values.
#
# DHCP-Do-Not-Respond can be used to tell the server to not
# respond.
#
# In the event that DHCP-Message-Type is not set then the
# server will fall back to determining the type of reply
# based on the rcode of this section.
#
#update reply {
# DHCP-Message-Type = DHCP-Offer
#}
#
# If DHCP-Message-Type is not set, returning "ok" or
# "updated" from this section will respond with a DHCP-Offer
# message.
#
# Other rcodes will tell the server to not return any response.
#
#ok
}
dhcp DHCP-Request {
# You must set the DHCP Server Identifier here since this is returned
# in ACKs and is used to determine whether a request containing a
# "server-ip" field is intended for this server
update control {
&DHCP-DHCP-Server-Identifier = 192.0.2.2
}
# If the request is not for this server then silently discard it
if (&request:DHCP-DHCP-Server-Identifier && \
&request:DHCP-DHCP-Server-Identifier != &control:DHCP-DHCP-Server-Identifier) {
do_not_respond
}
# Response packet type. See DHCP-Discover section above.
#update reply {
# &DHCP-Message-Type = DHCP-Ack
#}
# Call a policy (defined in policy.d/dhcp) to set common reply attributes
# dhcp_common
# Use a "passwd" module to set group memberships in DHCP-Group-Name
# Enable mods-available/dhcp_passwd to use this
#dhcp_group_membership
# Optionally override the network address based on client attributes
# See Discover section
#dhcp_override_network
# Use a "files" module to lookup global and subnet options
# For multiple subnets use this in place of dhcp_common
# Enable mods-available/dhcp_files AND uncomment dhcp_subnet in
# policy.d/dhcp to use this
# Options are set in mods-config/files/dhcp
dhcp_network
# Do a simple mapping of MAC to assigned IP.
#
# See below for the definition of the "mac2ip"
# module.
#
#mac2ip
# Or, allocate IPs from the DHCP pool in SQL. You may need to
# set the pool name here if you haven't set it elsewhere.
# update control {
# &Pool-Name := "local"
# }
dhcp_sqlippool_request
# If the IP was not allocated, do something else.
# You could call a Perl, Python, or Java script here.
#if (notfound) {
# ...
#}
# "Shared-networks" may have multiple IP subnets co-existing in a
# single Layer 2 network. If the pool for the network contains
# addresses from more that one subnet then the setting subnet-specific
# DHCP-Subnet-Mask, DHCP-Router-Address and DHCP-Broadcast-Address
# parameters must be performed after the allocation of the IP address.
#
# Set any subnet-specific parameters using this policy.
#
#dhcp_subnet
# Use a "files" module to lookup options based on DHCP-Group-Name
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
#dhcp_group_options
# Use a "files" module to lookup host specific options
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
#dhcp_hosts
# As an alternative or complement to configuration files based lookup
# for options data you can instead use an SQL database. Example
# configuration is found in dhcp_policy_sql in policy.d/dhcp which
# will need to be adapted to your requirements.
#dhcp_policy_sql
# If DHCP-Message-Type is not set, returning "ok" or
# "updated" from this section will respond with a DHCP-Ack
# packet.
#
# "handled" will not return a packet, all other rcodes will
# send back a DHCP-NAK.
#
#ok
}
#
# Other DHCP packet types
#
# There should be a separate section for each DHCP message type.
# By default this configuration will ignore them all. Any packet type
# not defined here will be responded to with a DHCP-NAK.
dhcp DHCP-Decline {
# Use a "passwd" module to set group memberships in DHCP-Group-Name
# Enable mods-available/dhcp_passwd to use this
#dhcp_group_membership
# Optionally override the network address based on client attributes
# See Discover section
#dhcp_override_network
# Use a "files" module to lookup global and subnet options
# For multiple networks use this in place of dhcp_common
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
dhcp_network
# Use a policy that set options from data stored in an SQL database
#dhcp_policy_sql
# If using IPs from a DHCP pool in SQL then you may need to set the
# pool name here if you haven't set it elsewhere and release the IP.
# update control {
# &Pool-Name := "local"
# }
# dhcp_sqlippool_decline
update reply {
&DHCP-Message-Type = DHCP-Do-Not-Respond
}
reject
}
#
# A dummy config for Inform packets - this should match the
# options set in the Request section above, except Inform replies
# must not set Your-IP-Address or IP-Address-Lease-Time
#
dhcp DHCP-Inform {
# Call a policy (defined in policy.d/dhcp) to set common reply attributes
# dhcp_common
# Use a "passwd" module to set group memberships in DHCP-Group-Name
# Enable mods-available/dhcp_passwd to use this
#dhcp_group_membership
# Optionally override the network address based on client attributes
# See Discover section
#dhcp_override_network
# Use a "files" module to lookup global and network options
# For multiple networks use this in place of dhcp_common
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
dhcp_network
# Use a policy with calls a "files" module of the same name to lookup
# subnet options
# Enable mods-available/dhcp_files AND uncomment dhcp_subnet in
# policy.d/dhcp to use this
# Options are set in mods-config/files/dhcp
#dhcp_subnet
# Use a "files" module to lookup options based on DHCP-Group-Name
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
#dhcp_group_options
# Use a "files" module to lookup host specific options
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
#dhcp_hosts
# Use a policy that set options from data stored in an SQL database
#dhcp_policy_sql
ok
}
#
# For Windows 7 boxes
#
#dhcp DHCP-Inform {
# update reply {
# Packet-Dst-Port = 67
# DHCP-Message-Type = DHCP-ACK
# DHCP-DHCP-Server-Identifier = "%{Packet-Dst-IP-Address}"
# DHCP-Site-specific-28 = 0x0a00
# }
# ok
#}
dhcp DHCP-Release {
# Use a "passwd" module to set group memberships in DHCP-Group-Name
# Enable mods-available/dhcp_passwd to use this
#dhcp_group_membership
# Optionally override the network address based on client attributes
# See Discover section
#dhcp_override_network
# Use a "files" module to lookup global and subnet options
# For multiple subnets use this in place of dhcp_common
# Enable mods-available/dhcp_files to use this
# Options are set in mods-config/files/dhcp
dhcp_network
# If using IPs from a DHCP pool in SQL then you may need to set the
# pool name here if you haven't set it elsewhere and release the IP.
# update control {
# &Pool-Name := "local"
# }
# dhcp_sqlippool_release
update reply {
&DHCP-Message-Type = DHCP-Do-Not-Respond
}
reject
}
dhcp DHCP-Lease-Query {
# The thing being queried for is implicit
# in the packets.
# has MAC, asking for IP, etc.
if (&DHCP-Client-Hardware-Address) {
# look up MAC in database
}
# has IP, asking for MAC, etc.
elsif (&DHCP-Your-IP-Address) {
# look up IP in database
}
# has host name, asking for IP, MAC, etc.
elsif (&DHCP-Client-Identifier) {
# look up identifier in database
}
else {
update reply {
&DHCP-Message-Type = DHCP-Lease-Unknown
}
ok
# stop processing
return
}
#
# We presume that the database lookup returns "notfound"
# if it can't find anything.
#
if (notfound) {
update reply {
&DHCP-Message-Type = DHCP-Lease-Unknown
}
ok
return
}
#
# Add more logic here. Is the lease inactive?
# If so, respond with DHCP-Lease-Unassigned.
#
# Otherwise, respond with DHCP-Lease-Active
#
#
# Also be sure to return ALL information about
# the lease.
#
#
# The reply types are:
#
# DHCP-Lease-Unknown
# DHCP-Lease-Active
# DHCP-Lease-Unassigned
#
update reply {
&DHCP-Message-Type = DHCP-Lease-Unassigned
}
}
}
######################################################################
#
# This next section is a sample configuration for the "passwd"
# module, that reads flat-text files. It should go into
# radiusd.conf, in the "modules" section.
#
# The file is in the format <mac>,<ip>
#
# 00:01:02:03:04:05,192.0.2.100
# 01:01:02:03:04:05,192.0.2.101
# 02:01:02:03:04:05,192.0.2.102
#
# This lets you perform simple static IP assignment.
#
# There is a preconfigured "mac2ip" module setup in
# mods-available/mac2ip. To use it do:
#
# # cd raddb/
# # ln -s ../mods-available/mac2ip mods-enabled/mac2ip
# # mkdir mods-config/passwd
#
# Then create the file mods-config/passwd/mac2ip with the above
# format.
#
######################################################################
# This is an example only - see mods-available/mac2ip instead; do
# not uncomment these lines here.
#
#passwd mac2ip {
# filename = ${confdir}/mac2ip
# format = "*DHCP-Client-Hardware-Address:=DHCP-Your-IP-Address"
# delimiter = ","
#}
Thanks
David
David Lake
Visiting Professor
5G Innovation Centre (5GIC and 6GIC)
Tel: +44 (0)7711 736784
Email: d.lake at surrey.ac.uk<mailto:%20d.lake at surrey.ac.uk>
Web: surrey.ac.uk<http://www.surrey.ac.uk/?utm_medium=internal&utm_source=emailsignature&utm_campaign=reputation+50th+brand>
[A blue text on a black background Description automatically generated]<http://www.surrey.ac.uk/?utm_source=emailsignature&utm_medium=internal&utm_campaign=emailsignature_1819&utm_content=emailsignature_homepage>
James Clerk Maxwell Building, University of Surrey, Guildford, Surrey, GU2 7XH, UK
-------------- next part --------------
A non-text attachment was scrubbed...
Name: image001.png
Type: image/png
Size: 8539 bytes
Desc: image001.png
URL: <http://lists.freeradius.org/pipermail/freeradius-users/attachments/20250717/e5c0da3a/attachment-0001.png>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: dhcp_relay_fail.pcap
Type: application/octet-stream
Size: 382 bytes
Desc: dhcp_relay_fail.pcap
URL: <http://lists.freeradius.org/pipermail/freeradius-users/attachments/20250717/e5c0da3a/attachment-0001.obj>
More information about the Freeradius-Users
mailing list
